CNC Automatic Pipe Bending Machine

CNC Automatic Pipe Bending Machine

CNC Automatic Pipe Bending Machine
CNC Automatic Pipe Bending MachineCNC Automatic Pipe Bending MachineCNC Automatic Pipe Bending MachineCNC Automatic Pipe Bending MachineCNC Automatic Pipe Bending Machine
CategoriesCNC Mandrel Tube Bender
BrandWONSTEN
Model75CNC
Product NameCNC Automatic Pipe Bending Machine
BendingHydraulic or Servo Motor
ControllerPLC or IPC
Feed and RotaryServo Motor
Update TimeMay 29,2024
Detail Information
Product Feature

China CNC Pipe Bending Machine plays an important role in construction and other fields, with high and reliable performance. The steel bar conveying table is composed of multiple power rollers, which complete the automatic conveying of steel bars and the storage of left and right. The lifting mechanism is pneumatically controlled, which can automatically position the reinforcing bar on the double bending machine head and transfer the bent reinforcing bar to the storage bin.

Product Description

The Automatic Hydraulic Pipe Bending Machine can be used together with NC-type steel shearing production line, which can automatically bend high-strength steel bars for construction. Compared with ordinary product on the market, it realizes the function to perform multi-directional bending at the same time in one work unit, and the two bending hosts can work at the same time, which greatly improves the efficiency, and greatly reduces labor intensity.

Operation Process

As the automatic pipe bender is an electronic device with a high degree of intelligence, its operation process is generally realized by professionals. The basic operation process can be simplified into the following steps. Let's have a look:

Normalization of tube shape -- standardization of bending radius -- determination of bending radius -- adjustment of bending forming speed -- determination of mandrel and its position
This is a title
1. bend-arm (C-axis) by hydraulic
2. clamp die, pressure die and side booster by hydraulic
3. motion up-down and motion left-right by hydraulic
4. carriage (Y-axis) by servo motor with programmable speed
5. collet (B-axis) grip by hydraulic, rotation by servo motor
6. mandrel by hydraulic with automatic lubrication & anticipated
    retraction
7. IPC based controller :
    Industrial PC assorted with touch-screen display, convertible
    between manual / automatic mode, convertible between inch
    metric setting, convertible between XYZ / YBC axes
    capable of reading igs/stp file
8. PLC based controller :
    PLC controller with touch screen display, convertible between
    manual / automatic mode, convertible between XYZ / YBC axes
    (optional)
