Pipe and Tube End Forming Machine

Pipe and Tube End Forming Machine

Pipe and Tube End Forming Machine
Pipe and Tube End Forming MachinePipe and Tube End Forming MachinePipe and Tube End Forming MachinePipe and Tube End Forming MachinePipe and Tube End Forming Machine
CategoriesTube End Forming Machine
BrandWONSTEN
ModelSG80
Product NamePipe and Tube End Forming Machine
Maxi. Forming CapacityCustomized
Forming StationSingle, Double and Triple Stations
ControllerPLC
Terms of PaymentL/C, T/T
Update TimeJun 24,2024
Detail Information
tube end forming machine
SG80 Pipe End Forming Machine

Human Interface offers easy access to auto and manual operating modes.

All the parts are made under very strict quality control, so the quality of machine is in high level and the specification is standardized.

Equipped with emergency stop device. Both manual and automatic operations are available.

Tube clamping and end forming driven by hydraulic.

Max. End Forming Capacity: ¢80×3mm

Max. End Forming Stroke: 150mm

End Forming Speed: 100/8-10 mm/sec

Max. Working Pressure: 16 Mpa

Motor Power: 7.5 Kw

We use good quality hardened tool steel material on our tube end forming tools for wear resistance.

Our tube end forming machines enable consistency, reliability, and fast production cycle times, and can be easily attached to a wide range of systems.
